VISIX 2MP IP Indoor Multi-Sensor Cube Camera w/ Wi-fi


The 3xLOGIC VX-2M-CPIR-IAW is a cube style, 2MP camera that goes far beyond being an IP video camera. A truly capable solution featuring built-in Passive Infrared (PIR) sensors, 2-way audio, and digital I/O allow the Multi-Sensor to be a feature-rich IP camera, alarm annunciator and audio system all in one small unit.

  • Overview
  • Benefits
  • Part Numbers

Using combinations of features, integrators can unlock the true potential of the Multi-Sensor.

Combine PIR and pixel-based motion detection to decrease false motion alarms. When an alarm is triggered into the digital I/O, use 2-way audio to communicate with site.

Dual-streaming compression provides recording at the highest quality while allowing fast live viewing from anywhere in the world regardless of available bandwidth.

Utilize the cameras optional edge recording for a true all-in-one solution or couple it with the VIGIL™ Series of Network Video Recorders (NVR) and Video Management System (VMS) software for superior point-to-point hardware compression and decompression, allowing for maximum performance of streamed live video, providing better video quality, more concurrent streams and a lower overall hit to CPU performance.

cube camera

Key Features & Benefits​ Include the Following

  • Lens (2.8mm Fixed, F2.0)​
  • Resolution (2 MegaPixel)​
  • 1920 x 1080 @ 30FPS ​
  • H.264, H.265, MJPEG​
  • 110° Angle of View ​
  • 10m IR Range​
  • Two-Way Audio Capable​
  • IR Cut Filter with Auto Switch​
  • 4-Year Warranty ​
  • Base Analytics​
# Name
VX-2M-CPIR-IAW VISIX 2MP Indoor Multi-Sensor Cube Style Camera with IR, PIR, Audio & WiFi
VX-2M-CPIR-IAW-S128 VISIX 2MP Indoor Multi-Sensor Cube Style Camera with IR, PIR, Audio & WIFI. Edge recording license and 128GB MicroSD card included
VX-CPIR-POWER-SUPPLY Power Supply for CPIR Camera - 100-240V, 12V/1A, 5.5x2.1x9.5mm 1.5M cord
